High Flow Quick Release Hydraulic Coupling for Massey Ferguson and Ford New Holland Tractors

Description

When you’re switching between implements all day long, fighting with hydraulic connections just eats up time and makes a mess of things. This Faster brand coupling turns those wrestling matches into simple push-and-click operations, saving time and reducing hydraulic contamination. No more fighting to connect implements or using screwdrivers to relieve pressure – this high-flow coupling handles the job like it should.

What You’re Getting

• Engineered specifically for high pressures with a pressure relief feature that allows connection even when there’s residual pressure in the lines
• High flow capacity at 70 LPM with 250 Bar maximum working pressure – handles demanding hydraulic applications without restriction
• M22 x 1.50 metric thread for secure connection to your tractor’s hydraulic system
• Precision-machined sealing surfaces maintain their integrity through thousands of connections, preventing leaks
• Push/pull coupling design with poppet valve for reliable operation and clean disconnection

Built for Real Farm Work

This coupling fits tractors built for versatility, handling everything from row crop farming and hay operations to loader work and specialty implement tasks – perfect when you need to switch between different hydraulic attachments throughout the day. Whether you’re disconnecting a front loader for transport, hooking up hydraulic-driven implements, or running high-flow attachments, this coupling handles the pressure and flow your modern tractor demands.

Made to Last

The robust construction handles the full system pressure without distortion, ensuring consistent performance season after season. These couplings are engineered to handle high pressures and flow rates while maintaining reliable sealing through thousands of connect/disconnect cycles, with improved design that provides better sealing and longer service life.

Installation Notes

Clean the threads thoroughly and check for damage before installation – even minor thread damage can cause leaks under high pressure. Use thread sealant appropriate for hydraulic systems, not standard pipe tape which can contaminate the system. The quick-release mechanism should operate smoothly – if it’s stiff, a drop of hydraulic oil on the mechanism usually frees it up. Always clean coupling faces before connecting to prevent contamination.
